Teltonika FMC150 is a professional telematics and GPS tracking solution designed for modern fleet management, cargo monitoring, security tracking, and vehicle telemetry applications. Future-proof 4G LTE Cat 1 tracker with 2G fallback and integrated CAN processor for high-speed OEM telemetry and diagnostics This device is suitable for logistics companies, transport operators, fleet managers, and security-focused vehicle tracking deployments.
| Network | 4G LTE Cat 1 with 2G (GSM) fallback (Bands: B1 / B3 / B7 / B8 / B20 / B28) |
|---|---|
| Bluetooth | Bluetooth 4.0 + LE (supports EYE Sensors, EYE Beacons, wireless temperature probes, and hands-free communication) |
| GNSS | 33-channel high-sensitivity receiver (GPS, GLONASS, Galileo, Beidou, QZSS, AGPS) |
| Antennas | Internal high-gain GNSS and LTE antennas with no external wiring required |
| CAN Support | Built-in CAN processor supporting 100+ vehicle parameters including EV battery status (SoC), charging state, and ICE engine metrics |
|---|---|
| Digital Inputs | 3 × inputs (Input 1 dedicated to ignition; remaining inputs configurable for doors or alarms) |
| Digital Outputs | 2 × open drain outputs for immobilization, buzzers, or external relay control |
| Analog Inputs | 2 × (0–30V) inputs for auxiliary sensors and battery monitoring |
| Negative Input | Software-configurable ground-trigger input for seatbelt and door sensors |
| 1-Wire Interface | Supports iButton Driver ID and up to 4 Dallas temperature sensors |
| Memory | 128MB internal flash memory for offline data storage during network interruptions |
| EV & Hybrid Monitoring | Real-time tracking of battery percentage, distance to empty, charging status, and energy consumption |
|---|---|
| ICE Fleet Data | Fuel level, odometer, engine RPM, engine temperature, and door status monitoring |
| Eco-Driving | Real-time analysis of harsh acceleration, braking, and cornering for improved safety and efficiency |
| Anti-Theft Suite | Jamming detection, unplug detection, and towing alarm protection |
| Crash Detection | Integrated 3-axis accelerometer for accident reconstruction and impact event reporting |
| Dimensions | 65 × 56.6 × 20.6 mm (55g) |
|---|---|
| Operating Voltage | 10V to 30V DC with overvoltage and reverse polarity protection |
| Backup Battery | 170mAh internal Li-Ion battery ensuring emergency alerts during power loss |
| IP Rating | IP41 (designed for professional in-cabin or dashboard installation) |
