Queclink GV75MG is a professional telematics and GPS tracking solution designed for modern fleet management, cargo monitoring, security tracking, and vehicle telemetry applications. Rugged, waterproof (IP67) tracker optimized for high-performance monitoring in harsh environmental conditions This device is suitable for logistics companies, transport operators, fleet managers, and security-focused vehicle tracking deployments.
| Network | Global LTE Cat M1 (eMTC) / NB1 (NB-IoT) with 2G EGPRS fallback |
|---|---|
| Data Transmission | eMTC: 375 Kbps (DL/UL); NB1: 32 Kbps DL / 70 Kbps UL |
| GNSS | u-blox all-in-one receiver (GPS/GLONASS) with <2.5m accuracy |
| Power Management | Zero power consumption mode prevents vehicle battery drain when ignition is off |
| Waterproof Rating | IP67 compliant (dustproof and water-resistant for outdoor and marine use) |
|---|---|
| Dimensions | 102 × 46 × 20.5 mm (110g) |
| Operating Temperature | -30°C to +80°C (industrial grade) |
| Housing | Vibration-resistant design suitable for quad bikes and watercraft |
| Serial Port | 1 × RS232 (8-pin waterproof cable) for external devices like cameras and sensors |
|---|---|
| Digital Inputs | 2 × inputs (1 positive ignition trigger, 1 negative general-purpose trigger) |
| Digital Outputs | 2 × outputs (including 1 with internal latch for secure immobilization) |
| Internal Battery | 700mAh Li-Polymer backup battery for extended operation during power loss |
|---|---|
| Driving Behavior | Harsh braking, acceleration, and aggressive maneuver detection |
| Crash & Tow Detection | 3-axis accelerometer for theft detection, crash analysis, and tow events |
| Memory Buffer | Stores up to 10,000 messages during cellular signal loss |
